The Line-EDS-PS is a Gateway with an embedded PowerStudio. This module allows, by itself, to configure a monitoring and remote management system (SCADA). It is capable of integrating, through the expansion modules of the line range or any Modbus equipment (TCP or RTU) on the market, any process signal that you want to measure. By programming the equipment with PowerStudio we can incorporate any logic of action on analog or digital outputs, so we can create an automated management system that performs actions based on the input signals. Connectivity to the computer can be done using wired (Ethernet) or wireless (Wi-Fi) networks. Access to the visualization of data, screens or reports can be done through the PowerStudio client or through a web browser thanks to the integrated web server. The PSS and PSS PRO variants have the ability to program screens and reports, which allows us to have a SCADA system with a single device, without the need for PCs, servers or licenses.

CVM-A1500 is a panel mounted power quality analyzer with EMS (Energy Management Software) integrated. Its internal Web Server (html5) allows any user to have full installation control by using any web browser. Designed to be installed in the most relevant or critical part of electric installations since it registers and monitors a wide range of variables (almost one year of data with RMS, maximum and minimum values). The device also registers power quality events such as swells, dips, interruptions (every half cycle) and transients (according to IEC 61000-4-30 Class A). Any event will be immediately captured with the voltage and current waveform. This model adds the measurement of power quality variables (defined in the standard EN 50160) such as flicker, unbalance (Kd) and asymmetry (Ka) coefficients or voltage and current harmonics decomposition up to 63th. In addition it is possible to monitor in real time the instantaneous waveforms of voltage and current through its oscilloscope function. As an added value, CVM-A1500 displays the number of events and transients on each affected phase with the level reached, duration and its associated waveform. In addition, those events are directly displayed in CBEMA, ITIC y SEMI-F47 graphs. The smart design of the CVM-A1500 allows users to customize their own screens in order to access to the information faster and easy. Remark that the device allows the connection though PowerStudio software to save and store, in a redundant way, all the information in a server or PC avoiding memory limits.

We manufacture a range of power monitoring units, including VAR transducers, watt transducers, combined Watt / VAR transducers, mains frequency to current / voltage converters, power factor transducers, AC current and voltage transducers.
